Description

☆ HDMI 2.1 and HDCP 2.3 compliant

☆ Support 40Gbps video bandwidth

☆ Support video resolution up to 8K@60Hz 4:2:0 10bit, 8K@30Hz 4:4:4

10bit, 4K@120Hz 4:4:4 10bit

☆ VRR, FVA, ALLM supported

☆ Support HDR, HDR10, HDR10+, Dolby Vision, HLG pass through

☆ Support HDMI audio formats: LPCM, Dolby Digital/Plus/EX, Dolby True

HD, Dolby Atmos, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD

Master Audio, DSD

☆ INPUTS 1 port and OUT 1 port support eARC/ARC function

☆ Allows HD audio up to Dolby Atmos, DTS:X over TrueHD from ANY

external HDMI source to any eARC/ARC sound system

☆ Support audio de-embedding function (output through the optical and

analog port)

☆ Built-in EDID DIP switch supports advanced EDID management

☆ 8K->4K, 8K/4K->2K downscaler support

☆ Support IR remote control and front panel button switching

☆ Built-in Equalizer, Retiming and Driver

☆ Compact design for easy and flexible installation
