Description

☆ HDCP 2.2 compliant

☆ Support 18Gbps video bandwidth

☆ Support video resolution up to 4K2K@60Hz RGB/YCBCR 4:4:4, as

specified in HDMI 2.0b

☆ The transmission distance can be extended up to 230ft/70m via a

single CAT6/6a cable

☆ Support HDR, HDR10, HDR10+, Dolby Vision, HLG

☆ Audio formats: LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD,

Dolby Digital Plus(DD+)

☆ Support 3.5mm analog audio de-embedding, audio is output through the

L/R OUT port of the receiver

☆ EDID copy pass-through function between the source device and

display device

☆ Support bi-directional POC (Power over Cable) function

☆ With USB KVM pass-through function, USB1.1 compliant, support

remote-control by keyboard and mouse

☆ Compact design for easy and flexible installation
